EM060K-GL IoT 4G Modules EM061K-GL M060KGLAA-M22-SGADA

Model Number : EM060K-GL

Place of Origin : China

Brand Name : QT

Packaging Details : Export standard pack

Supply Ability : 50000 Piece/Pieces per Week

Price : $43.00 - $49.88/pieces

Type : LTE Module, 4G CAT 6 Module

Chipset : EM060K-GL

Application : M2M, Wireless, IoT, M2M

Product name : EM060K-GL

Package : M2

Condition : Original & New

Area : Global

Shipping by : DHL\UPS\Fedex\EMS

Payment : Paypal\TT\Western Union\Trade Assurance

Size : 42.0mm * 30.0mm * 2.3mm

Extended temperature : -40°C ~ +85°C

Contact Now

EM060K-GL 4G IoT Modules EM061K-GL M060KGLAA-M22-SGADA Original for Your Requirements

Product Description

EM060K-GL IoT 4G Modules EM061K-GL M060KGLAA-M22-SGADA

EG060K-EA

The EM060K-GL is an LTE-A Cat 6 module with an M.2 form factor measuring 42.0mm × 30.0mm × 2.3mm, developed in accordance with the 3GPP Release 12 specification, which supports a theoretical downlink peak data rate of 300Mbps and a theoretical uplink peak data
rate of 50Mbps. The module is compatible with LTE-A Cat 6 module EM06, Cat 12 modules EM12-G/EM121R-GL/EM120R-GL,Cat 16 module EM160R-GL and 5G modules RM500Q/RM502Q Series, which enables migration between different modules.

The EM060K-GL is designed for the global market and covers nearly all mainstream carriers worldwide. The module supports at location technology gpsOne 9HT (GPS, GLONASS, BeiDou/Compass and Galileo). The integrated GNSS greatly simplifies product design, and provides quicker, more accurate and more dependable positioning capability.

A rich set of Internet protocols, industry-standard interfaces and abundant functionalities (USB drivers for Windows, Linux,
Android/optional built-in eSIM) allow the module to serve a wide range of applications such as industrial routers, home gateways, STB, industrial laptops, consumer laptops, industrial PDAs, rugged tablet PCs, and digital signage.

Key Benefits
● LTE-A Cat 6 module with M.2 form factor
● Support DL 2 Carrier Aggregation and 64QAM
● Worldwide LTE-A and UMTS/HSPA+ coverage
● Built-in eSIM (optional), DSSA
● Multi-constellation GNSS receiver available for applications requiring fast and accurate fixes in any environment
● MIMO technology meets demands for data rate and link reliability in modem wireless communication systems

LTE Cat 6	EG060K-EA
Region/ Operator	Global
Dimensions (mm)	30.0 mm × 42.0 mm × 2.3 mm
Frequency Bands
LTE-FDD	B1/B2/B3/B4/B5/B7/B8/B12/B13/B14/B17/B18/B19/B20/B25/B26/B28/B29①/B30/B32①/B66/B71
LTE-TDD	B34/B38/B39/B40/B41/B42/B43/B46① (LAA)/B48 (CBRS)
DL 2CA	Intra-band and Inter-band
WCDMA	B1/B2/B3/B4/B5/B6/B8/B19
GNSS	GPS/GLONASS/BDS/Galileo
